Description
Engine / Drive Train Specifications
Engine: 229.2cc, 4-stroke
Cylinder Arrangement: Single cylinder
Max Horsepower: 14.75HP/7500RPM
Max Torque: 12.17ft-lb/5500RPM
Bore × Stroke: 67mm x 65mm
Compression Ratio: 9.0:1
Cooling System: Air cooled
Transmission: 5-Speed, Manual
Start System: Electric and Kick Start
Ignition: CDI
Final Drive: Chain drive
Max Speed: 60MPH
Battery: 12V6.5Ah
Frame / Body / Suspension / Brakes
Front Suspension: Dual hydraulic forks and shock absorbers.
Rear Suspension: Swing arm with central shock absorber.
Front Brake: Hydraulic disc brake.
Rear Brake: Hydraulic disc brake
Front Tires: 80/100-21
Rear Tires: 110/100-18
Capacities / Dimensions
Max Load: 331lbs
Gross Weight: 310.9lbs
Net Weight: 275.63lbs
Overall Length: 82.3inches
Overall Width: 36.2inches
Overall Height: 56.7inches
Carton Dimensions (L × W × H): 69.69×18.11×33.86inches
Seat Height: 35.4inches
Wheelbase: 53.93inches
Ground Clearance: 8.3inches
Gas Tank Capacity: 3.7gal
Fuel Consumption: 65.34mpg
Available colors: Black, Red, Blue, Green.
